Pipe Class

Smap3D Pipe Specs

"Industrial Pipe Specs" for Smap3D Plant Design significantly simplify and speed up pipeline design: The add-on contains predefined pipe specs for different industries and sorts them according to different characteristics. This allows plant engineers to quickly find the appropriate pipe spec for individual adaptation.

  • Quick definition of all required pipe specs: through pre-defined industrial pipe specs
  • Fast implementation: Faster entry into the production phase and faster design launch
  • Simple handling: 1. selection according to suitable or similar pipe spec 2. adaptation to individual requirements
  • Cost-effective licensing: only one license per company, regardless of number of users
  • Selection of typical pipe specs from various industries: Oil and gas, chemical, water treatment, hydraulic, food, beverage and pharmaceutical industries
  • Selection of relevant features:
    design guideline, nominal pressure, media (such as water, gas, air, oil),
    temperature range, nominal diameter, sealing surface,
    base materials pipes (such as stainless steel, steel, carbon steel, plastic),
    fittings, seals (such as spiral seals, various rubber seals, DTVE), corrosion surcharge

Better planning in all areas with Smap3D Plant Design:

P&IDPipingPipe specificationsIsometricSteelSteel to NCPDM/ERP-ConnectorElectricPipe productions3D-Bending SimulationStress Simulation3D-Laserscans
